2023 Arctic Cat Prowler Pro Crew XT

Stock #301700
MSRP: $19,999 USD

217 people have recently viewed it.
Check Availability
Hi, my name is and I'm interested in this 2023 Arctic Cat Prowler Pro Crew XT . I'm in the area and you can reach me at or by phone at
  • Status:
    New
  • Vehicle:
    2023 Arctic Cat Prowler Pro Crew XT
  • VIN:
    4UF1R4KB6PT301700
  • Model Number:
    Prowler Pro Crew XT
  • Mileage:
    1 miles
  • Color:
    Phantom Grey
  • Stock Number:
    301700
  • Title:
    Clear
  • Location:
    Bay Cycle Sales
  • Warranty:
    Manufacturer's w/ Extended Available

BRAKES

  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc

DRIVE LINE

  • Differential Lock Location:
    Rear
  • Driveline Type:
    Selectable 4X2 / 4X4
  • Number Of Driveline Modes:
    3
  • Rear Unlocking Differential:
    Yes

ENGINE

  • Carburetion Type:
    Fuel Injected
  • Cooling:
    Liquid
  • Cylinders:
    3
  • Displacement (cc):
    812
  • Displacement (ci):
    49.5
  • Engine Stroke:
    4-Stroke
  • Engine Type:
    In-Line
  • Fuel Injector:
    Yes
  • Fuel Requirements:
    Regular
  • Fuel Type:
    Gas
  • Horsepower (bhp):
    50
  • Horsepower (kW):
    37.3
  • Starter:
    Electric
  • Torque (Ft Lbs):
    48
  • Torque (Nm):
    65.1
  • Valve Configuration:
    DOHC
  • Valves Per Cylinder:
    4
  • Valves:
    4

EXTERIOR

  • A-Arm Skid Plate (Front):
    Yes
  • A-Arm Skid Plate (Rear):
    Yes
  • Bash Plate (Front):
    Yes
  • Body Material:
    Plastic
  • Brush Guard:
    Yes
  • Cab Canopy Material:
    Hard
  • Cab Door Material:
    Hard
  • CV Boot Cover:
    Yes
  • Engine Case Guard:
    Yes
  • Frame:
    Steel
  • Full Length Skid Plate:
    Yes
  • Radiator Guard:
    Yes

INSTRUMENTATION

  • Fuel Level Warning Type:
    Gauge
  • Temperature Warning Type:
    Light

LIGHTS

  • Type:
    Halogen

SEATS

  • Folding:
    Yes
  • Headrest:
    Yes
  • Number Of Rows:
    2
  • Number Of Seats:
    6
  • Seat Height (in):
    31.3
  • Seat Height (mm):
    794
  • Seat Material:
    Vinyl
  • Seat Type:
    Bench

STEERING

  • Steering Control:
    Steering Wheel
  • Steering Type:
    Power

STORAGE

  • Bed Capacity (kgs.):
    453.6
  • Bed Capacity (lbs.):
    1000
  • Bed Height (in):
    11.5
  • Bed Height (mm):
    292
  • Bed Length (in):
    40.5
  • Bed Length (mm):
    1029
  • Bed Volume (ft3):
    14.7
  • Bed Volume (m3):
    0.4
  • Bed Width (in):
    54
  • Bed Width (mm):
    1372
  • Cargo Bed Material:
    Polyethylene
  • Cargo Bed Tilt:
    Yes
  • Integral Tie-Down Hooks:
    Yes

SUSPENSION

  • Front Suspension Type:
    Independent Double A-Arm
  • Front Travel (in):
    10
  • Front Travel (mm):
    254
  • Number Rear Shock Absorbers:
    2
  • Rear Suspension Material:
    Steel
  • Rear Suspension Type:
    Independent Double A-Arm
  • Rear Travel (in):
    9.5
  • Rear Travel (mm):
    241

TECHNICAL SPECIFICATIONS

  • Dry Weight (kg):
    889.5
  • Dry Weight (lbs):
    1961
  • Engine Displacement to Weight (cc):
    0.41
  • Fuel Capacity (gal):
    10
  • Fuel Capacity (l):
    37.9
  • Ground Clearance (in):
    12.5
  • Ground Clearance (mm):
    317.5
  • Height (in):
    78
  • Height (mm):
    1980
  • Length (ft):
    13.57
  • Length (ft/ft):
    13
  • Length (ft/in):
    6.8
  • Length (in):
    162.8
  • Length (mm):
    4135
  • Payload Capacity (kgs):
    680.4
  • Payload Capacity (lbs):
    1500
  • Storage Capacity (cuft):
    18
  • Storage Capacity (gal):
    115.7
  • Storage Capacity (l):
    509.7
  • Towing Capacity (kgs):
    907.2
  • Towing Capacity (lbs):
    2000
  • Wheelbase (in):
    118.5
  • Wheelbase (mm):
    3010
  • Width (in):
    63
  • Width (mm):
    1600

TOWING & HAULING

  • Rear Hitch Type:
    Receiver
  • Size (cm):
    50.8
  • Size (in):
    2
  • Weight (kgs):
    2041.2
  • Weight (lbs):
    4500
  • Winch Brand Name:
    Warn®

TRANSMISSION

  • Hi / Low Range:
    Yes
  • Primary Drive (Engine / Transmission):
    Belt
  • Primary Drive (Front Wheel):
    Shaft
  • Primary Drive (Rear Wheel):
    Shaft
  • Reverse:
    Yes
  • Transmission Type:
    Continuously Variable (CVT)

WHEELS & TIRES

  • Front Tire (Full Spec):
    Duro 26 X 9-14
  • Front Tire Diameter (in):
    26
  • Front Tire Width:
    9
  • Front Wheel Diameter:
    14
  • Rear Tire (Full Spec):
    Duro 26 X 11-14
  • Rear Tire Diameter (in):
    26
  • Rear Tire Width:
    11
  • Rear Wheel Diameter:
    14
  • Tire Brand:
    Duro
  • Tread Type:
    All Terrain
  • Wheels Composition:
    Aluminum
